FALLER CH-47D Chinook

FALLER 01622 1/72 CH-47D Chinook Helicopter Model Kit Instruction Manual

Detailed Assembly and Care Guide

1. Einleitung

This instruction manual provides comprehensive guidance for the assembly, maintenance, and care of your FALLER 01622 1/72 CH-47D Chinook Helicopter plastic model kit. The CH-47 Chinook is a tandem-rotor, heavy-lift helicopter used by military forces worldwide for troop transport, cargo, and various support missions. This model kit accurately represents the CH-47D variant at a 1:72 scale.

Please read all instructions carefully before beginning assembly to ensure a successful and enjoyable building experience.

2. Sicherheitshinweise

  • Aufsicht durch Erwachsene: This model kit is intended for adult hobbyists. Adult supervision is recommended for younger builders.
  • Kleine Teile: The kit contains small parts that may pose a choking hazard. Keep out of reach of small children.
  • Scharfe Werkzeuge: Assembly requires the use of sharp tools such as hobby knives and tweezers. Handle with care to prevent injury.
  • Klebstoffe und Farben: Use model-specific adhesives and paints in a well-ventilated area. Follow the manufacturer's safety instructions for these products.
  • Augenschutz: Consider wearing eye protection during assembly, especially when cutting or sanding parts.

3. Packungsinhalt

Before starting, verify that all components are present in your kit. The box should contain:

  • Plastic sprues with helicopter parts
  • Clear plastic parts (canopy, windows)
  • Photo-etched parts (for enhanced detail)
  • Aufkleberbogen
  • Bedienungsanleitung (diese Anleitung)
Box art of the FALLER 01622 1/72 CH-47D Chinook Helicopter model kit, showing the assembled helicopter in flight.

Figure 1: The FALLER 01622 1/72 CH-47D Chinook Helicopter model kit box art. This image displays the completed model, providing an overview of the helicopter's appearance and scale.

4. Benötigtes Werkzeug (nicht im Lieferumfang enthalten)

The following tools are recommended for assembly:

  • Side cutters or sprue nippers
  • Hobby knife with a sharp blade
  • Feinkörniges Schleifpapier oder Schleifstäbe
  • Plastic model cement (liquid or tube type)
  • Tweezers (fine-tipped recommended for photo-etched parts)
  • Klein files (optional, for cleaning parts)
  • Paint brushes and model paints (optional, for finishing)
  • Decal setting solution (optional)

5. Einrichtung und Vorbereitung

  1. Arbeitsplatz: Prepare a clean, well-lit, and well-ventilated workspace. Protect your work surface with a cutting mat or old newspaper.
  2. Teile organisieren: Carefully remove all sprues from the box. Familiarize yourself with the parts layout by comparing them to the parts diagram in the instruction booklet.
  3. Anweisungen lesen: Review the entire instruction manual before cutting any parts. This helps in understanding the overall assembly sequence.

6. Montageanleitung

Follow these steps in the order presented. Refer to the diagrams in the original kit instructions for visual guidance.

  1. Fuselage Halves: Carefully remove the two main fuselage halves from their sprues. Clean any mold lines or excess plastic using a hobby knife and sandpaper. Test fit the halves together before applying cement. Once satisfied with the fit, apply a thin layer of plastic cement along the mating surfaces and firmly press them together. Use tape or clamps to hold them until dry.
  2. Cockpit-Montage: Assemble the cockpit interior components, including the instrument panel, control sticks, and seats. Paint these parts before assembly if desired. Once painted, glue them into one of the fuselage halves.
  3. Fahrwerk: Assemble the landing gear struts and wheels. Ensure proper alignment. Attach the completed landing gear assemblies to the designated points on the lower fuselage.
  4. Rotor Assemblies: Construct the front and rear rotor hubs and blades. Pay close attention to the orientation of the blades. The CH-47D features two counter-rotating rotors.
  5. Engines and Nacelles: Assemble the engine nacelles and attach them to the top of the fuselage.
  6. Photo-Etched Parts: Carefully cut and bend the photo-etched parts as indicated in the kit instructions. Use super glue or a specialized photo-etch adhesive for these delicate components. These parts often represent fine details like grilles or antennas.
  7. Klarsichtteile: Attach the clear canopy and window parts using clear parts cement or white glue to avoid fogging the plastic. Ensure a tight fit to prevent dust ingress.
  8. Letzte Details: Add any remaining external details such as antennas, lights, and external fuel tanks (if included).
  9. Abziehbilder: Once the model is fully assembled and painted (if applicable), apply the decals. Cut each decal close to its edge, dip it in warm water for a few seconds, and slide it onto the model. Use decal setting solution to help them conform to irregular surfaces and eliminate silvering.

7. Wartung und Pflege

To preserve the appearance and integrity of your assembled model:

  • Abstauben: Regularly dust the model with a soft, dry brush or a can of compressed air. Avoid abrasive cloths.
  • Reinigung: Hartnäckigen Schmutz mit einem leicht feuchten Tuch vorsichtig abwischen.amp cloth. Avoid harsh chemicals or solvents, as they can damage paint and plastic.
  • Anzeige: Display your model in a stable, dust-free environment away from direct sunlight, extreme temperatures, and high humidity. UV light can cause paint and decals to fade over time.
  • Handhabung: Handle the model by its sturdy parts, such as the fuselage, to avoid damaging delicate components like antennas or rotor blades.

8. Fehlerbehebung bei häufigen Problemen

Ausgabe Mögliche Ursache Lösung
Die Teile passen nicht zusammen Überschüssiger Kunststoff (Grat), Formtrennnähte oder falsche Teileausrichtung. Carefully trim excess plastic with a hobby knife or sand mold lines. Double-check the instruction diagrams for correct part orientation.
Decals "silver" (appear shiny with air bubbles) Air trapped under the decal, or surface not smooth enough. Apply a gloss coat before decals. Use decal setting solution to help decals conform and eliminate air. Puncture small bubbles with a sharp needle.
Glue marks on clear parts Using standard plastic cement, which can fog clear plastic. Always use clear parts cement or white glue for clear plastic. If fogging occurs, it is often irreversible; prevention is key.

9. Produktspezifikationen

  • Marke: FALLER
  • Modellname: CH-47D Chinook
  • Skala: 1:72
  • Materialart: Plastik
  • Artikelabmessungen (L x B x H): Approximately 10.03 x 16.48 x 4 inches (packaging dimensions, actual model size will vary)
  • Artikelgewicht: 0.16 Kilograms (packaging weight)
  • Altersspanne (Beschreibung): Erwachsene
  • Enthaltene Komponenten: Model parts, instructions (English language not guaranteed in original kit)
  • Zusätzliche Funktionen: Photo-etched parts included
  • Hersteller: Stevens International

10. Garantieinformationen

Dieses Produkt wird mit einem 30-Tage-Garantie gegen Herstellungsfehler. This warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from improper assembly, misuse, accidents, or modifications. Please retain your proof of purchase for warranty claims.

11. Kundendienst

For technical assistance, missing parts, or warranty inquiries, please contact the manufacturer, Stevens International, or your retailer. When contacting support, please have your model number (01622) and proof of purchase readily available.

Note: The original kit instructions may not be in English. This manual aims to provide clear English guidance.

© 2024 FALLER. All rights reserved.
