Sublue Mix Underwater Scooter Instruction Manual

1. Produktüberschreitungview

The Sublue Mix is a compact and powerful underwater scooter designed to enhance your water exploration. It features dual motors, offering two-speed settings for varied underwater experiences. The device is equipped with a detachable buoyancy chamber, allowing for flexible use in different water depths and activities like snorkeling, scuba diving, and freediving. An integrated action camera mount enables users to capture underwater moments.

Zu den Hauptmerkmalen gehören:

• Doppelmotoren: Provides 22 lbf of thrust for efficient propulsion.
• Zwei Geschwindigkeitseinstellungen: Offers speeds of 1.2 m/s (2.68 mph) and 1.6 m/s (3.58 mph).
• Detachable Buoyancy Chamber: Allows the scooter to float when attached or sink for deeper dives when removed.
• Herausnehmbarer Akku: 11,000 mAh waterproof battery provides up to 45 minutes of intermittent use.
• Wasserdichtigkeit: Operates safely up to 131 feet (40 meters) depth.
• Action-Kamerahalterung: Compatible with most action cameras for recording.
• Leicht und tragbar: Weighs 7.72 lbs (3.5 kg) for easy transport.

Image 1.1: The Sublue Mix Underwater Scooter in use by a diver.

2. Aufbau und Montage

Before first use, ensure all components are present and correctly assembled. The package includes the Mix scooter with floater, a 122Wh rechargeable battery, a standard charger, an anti-lost lanyard, and this instruction manual.

2.1. Einbau und Aufladen der Batterie

1. Laden Sie den Akku auf: Connect the 122Wh rechargeable battery to the standard charger and plug it into a power outlet. Ensure the battery is fully charged before initial use. A full charge typically takes approximately two hours.
2. Installieren Sie die Batterie: Open the battery compartment on the Sublue Mix scooter. Insert the fully charged battery, ensuring it clicks securely into place. Close the battery compartment cover firmly to maintain its waterproof seal.

Image 2.1: Inserting the removable battery into the Sublue Mix scooter.

2.2. Attaching the Buoyancy Chamber (Floater)

The buoyancy chamber (floater) provides positive buoyancy, allowing the scooter to float. This is recommended for snorkeling or shallow water use to prevent loss. For deeper diving, the floater can be removed.

1. Attach Floater: Align the buoyancy chamber with the top of the scooter and press it firmly until it locks into place.
2. Remove Floater: Press the release buttons (if present) or slide the floater off the scooter.

Image 2.2: Illustration of attaching and detaching the buoyancy chamber.

2.3. Attaching the Anti-Lost Lanyard

Always attach the anti-lost lanyard to your wrist or equipment to prevent the scooter from drifting away, especially in currents or when diving without the buoyancy chamber.

1. Sicheres Lanyard: Fasten the lanyard to the designated attachment point on the scooter and secure the other end to your wrist.

2.4. Action Camera Installation

The Sublue Mix includes a mount for action cameras. Attach your compatible action camera to this mount to record your underwater adventures.

Image 2.3: Sublue Mix with an action camera mounted.

3. Bedienungsanleitung

3.1. Ein-/Ausschalten

1. Einschalten: Press and hold the power button located on the handle until the indicator lights illuminate.
2. Ausschalten: Drücken und halten Sie den Netzschalter erneut, bis die Kontrollleuchten erlöschen.

3.2. Geschwindigkeitsregelung

The Sublue Mix features a 2-speed gear switch to adjust thrust.

• Langsame Geschwindigkeit: 1.2 m/s (2.68 mph) for relaxed cruising and extended battery life.
• Hohe Geschwindigkeit: 1.6 m/s (3.58 mph) for faster movement and more exhilarating rides.

To change speed, press the speed switch button on the handle. The indicator lights will show the current speed mode.

Image 3.1: Visual representation of the two-speed settings.

3.3. Underwater Operation

1. Hold the Scooter: Grip the handles firmly with both hands.
2. Engage Thrusters: Press the trigger buttons on both handles simultaneously to activate the dual motors. Release either button to stop the scooter.
3. Richtungssteuerung: Steer by shifting your body weight and slightly angling the scooter. The dual propellers provide stable, straight gliding.

Image 3.2: Demonstrating the scooter's thrust in action.

3.4. Akkulaufzeit und Nutzung

The 11,000 mAh battery offers varying runtimes:

• Up to 45 minutes of intermittent use.
• Approximately 30 minutes at continuous low speed.
• Approximately 20 minutes at continuous high speed.

Actual runtime may vary based on user weight, water conditions, and speed settings. Consider purchasing zusätzliche Batterien für längere Nutzungsdauer.

4. Wartung und Pflege

Proper maintenance ensures the longevity and optimal performance of your Sublue Mix underwater scooter.

4.1. Nach jeder Verwendung

• Abspritzen: Thoroughly rinse the scooter with fresh water immediately after use, especially after saltwater exposure. Pay attention to the propellers and seals.
• Trocken: Wipe the scooter dry with a soft cloth. Ensure all water is removed from the battery compartment and charging ports before storage or recharging.
• Überprüfen: Check for any signs of damage, wear, or debris in the propellers.

4.2. Batteriepflege

• Lagerung: Store the battery in a cool, dry place, away from direct sunlight and extreme temperatures. For long-term storage, charge the battery to approximately 50-60%.
• Laden: Only use the provided standard charger. Do not overcharge or leave unattended for extended periods.
• Handhabung: Avoid dropping or puncturing the battery. If the battery appears damaged or swollen, discontinue use and dispose of it properly.

4.3. Speicherung

Store the Sublue Mix in a dry, shaded area. If storing for an extended period, remove the battery. The compact design allows for easy storage in a backpack or carrying case.

5. Fehlerbehebung

This section addresses common issues you might encounter with your Sublue Mix underwater scooter.

If you encounter issues not listed here or if solutions do not resolve the problem, please contact Sublue customer support.

6. Spezifikationen

7. Garantie und Support

7.1. Garantieinformationen

The Sublue Mix Underwater Scooter comes with a 1 Jahr Garantie from the date of purchase. This warranty covers manufacturing defects. Please retain your proof of purchase for warranty claims. The warranty does not cover damage caused by misuse, accidents, unauthorized modifications, or improper maintenance.

7.2. Kundendienst

For technical assistance, warranty claims, or any product-related inquiries, please contact Sublue Customer Support:

• E-Mail: amazon.store@sublue.com
• Gebührenfreier Support: 855-206-8698
• Kundendienst: 951-208-7172
• Öffnungszeiten: Monday - Friday, 9 am - 6 pm (PST)

Sublue aims to provide a response within 24 hours during business days.

Image 7.1: Sublue customer support details.
