NITHO Drive Pro ONE V24 Racing Wheel with Pedals User Manual

Einführung

This manual provides detailed instructions for the setup, operation, and maintenance of your NITHO Drive Pro ONE V24 Racing Wheel with Pedals. Please read this guide thoroughly before using the product to ensure proper functionality and a safe gaming experience. The Drive Pro ONE V24 is designed for use with PlayStation 4, Xbox Series X/S, Xbox One, PC (X-Input), and Nintendo Switch. Please note that this product is intended for arcade games only.

Bild: Vorderseite view of the NITHO Drive Pro ONE V24 Racing Wheel, showcasing seine Konstruktion und Steuerung.

Packungsinhalt

Bitte überprüfen Sie, ob alle unten aufgeführten Artikel in Ihrem Paket enthalten sind:

• NITHO Drive Pro ONE V24 Racing Wheel
• Pedaleinheit (Gas und Bremse)
• USB-Verbindungskabel
• Montage Clamps (2 Einheiten)
• Removable Suction Cups (5 units)
• Benutzerhandbuch (dieses Dokument)

Image: Contents of the box, showing the racing wheel, pedal unit, cables, and mounting accessories.

Aufstellen

1. Montage des Rennlenkrads

The Drive Pro ONE V24 offers two mounting options for stability:

Mit Montageklamps:

1. Befestigen Sie die beiden Befestigungsklammernamps to the designated slots on the underside of the racing wheel base.
2. Place the racing wheel on a stable surface (e.g., a desk or racing stand).
3. Ziehen Sie die Klammer fest.amps securely to prevent movement during use. Ensure the surface thickness is compatible with the clamps.

Abbildung: Illustration des clamp mounting system, demonstrating how to secure the wheel to a surface.

Using Removable Suction Cups:

1. The racing wheel base is equipped with five removable suction cups.
2. Ensure the surface is clean and smooth for optimal suction.
3. Press the wheel firmly onto the surface to engage the suction cups.
4. To remove, gently lift the edges of the suction cups. These can be removed if not needed for a more stable clamp Installation.

Image: Diagram illustrating the removable suction cups on the underside of the racing wheel, highlighting their function.

2. Anschließen der Pedaleinheit

Connect the cable from the pedal unit to the designated port on the back of the racing wheel base.

3. Verbindung zu Ihrem Spielsystem herstellen

Connect the USB cable from the racing wheel to an available USB port on your console (PlayStation 4, Xbox Series X/S, Xbox One, Nintendo Switch) or PC. The system should automatically detect the device. For PC, the wheel operates in X-Input mode.

Image: A circular diagram illustrating the multi-platform compatibility of the racing wheel, including Switch, PS4, PS3, Xbox One, Xbox Series, and PC.

Bedienungsanleitung

1. Steering Wheel Operation

The NITHO Drive Pro ONE V24 features a 10-inch (255mm) steering wheel with a 270-degree lock-to-lock rotation. This allows for precise steering control in racing games. The high-quality rubber grips provide a comfortable and secure hold during gameplay. The robust and precise internal mechanism is designed to simulate realistic driving sensations, allowing you to feel understeer, oversteer, and drifts.

Image: A visual representation of the steering wheel's 270-degree rotation capability.

Image: An illustration depicting the internal mechanism of the racing wheel, contributing to a realistic driving experience.

2. On-Wheel Controls

The steering wheel is equipped with 28 action buttons, a D-Pad, and an analog stick for comprehensive control within your games. Refer to your game's control settings to customize button assignments as needed.

Bild: Detailliert view of the central part of the steering wheel, showing the various buttons, D-Pad, and analog stick.

3. Paddle Shifters

Utilize the integrated paddle shifters located behind the steering wheel for quick and responsive gear changes, enhancing your racing experience.

Image: An illustration showing the paddle shifters located behind the steering wheel, indicating their function.

4. Pedal Unit Usage

The compact XL pedal unit includes an analog accelerator and a non-linear brake pedal, providing realistic feedback for acceleration and braking. Position the pedal unit on the floor for comfortable use.

Bild: Ein klares view of the two-pedal unit, featuring the accelerator and brake pedals.

5. Vibration Effect

The racing wheel features a vibration effect that provides tactile feedback, simulating in-game events such as collisions, road textures, and engine RPMs, enhancing immersion.

Image: An illustration of the steering wheel with wavy lines indicating the vibration effect.

Wartung

To ensure the longevity and optimal performance of your NITHO Drive Pro ONE V24 Racing Wheel, follow these maintenance guidelines:

• Reinigung: Use a soft, dry cloth to wipe down the racing wheel and pedal unit. Avoid using abrasive cleaners or solvents, as these can damage the surfaces.
• Lagerung: Bewahren Sie das Gerät bei Nichtgebrauch an einem sauberen, trockenen Ort fern von direkter Sonneneinstrahlung und extremen Temperaturen auf.
• Kabelpflege: Vermeiden Sie scharfe Biegungen oder Knicke in den Kabeln. Ziehen Sie nicht an den Kabeln, um das Gerät zu trennen.

Fehlerbehebung

If you encounter issues with your NITHO Drive Pro ONE V24, please refer to the following common solutions:

• Gerät nicht erkannt:
  • Ensure all cables are securely connected to both the racing wheel and your gaming system/PC.
  • Versuchen Sie, das USB-Kabel an einen anderen USB-Anschluss anzuschließen.
  • Starten Sie Ihre Spielkonsole oder Ihren PC neu.
  • For PC, ensure necessary drivers are installed (usually automatic, but check device manager).
• Keine Vibrationsrückmeldung:
  • Vergewissern Sie sich, dass das Spiel, das Sie spielen, Vibrationsfeedback unterstützt.
  • Überprüfen Sie die Spieleinstellungen, um sicherzustellen, dass die Vibration aktiviert ist.
• Falsche Tastenbelegung:
  • Access the control settings within your game to remap buttons as desired.
  • Some games may require manual configuration for optimal performance.
• Steering or Pedal Inaccuracy:
  • Ensure the wheel is securely mounted and not shifting during use.
  • Calibrate the wheel and pedals if your game or system offers this option.
• Compatibility Issues (Nintendo Switch/Xbox):
  • While the product is designed for multi-platform compatibility, some users have reported specific game or system configurations requiring adjustments. Ensure your console's firmware is up to date.
  • Remember this product is primarily for arcade-style racing games.

If the problem persists, please contact NITHO customer support for further assistance.

Technische Daten

Image: Detailed diagram displaying the width, height, and depth measurements for both the racing wheel and the pedal unit.

Garantie und Support

NITHO products are manufactured to high-quality standards. For warranty information or technical support, please refer to the warranty card included in your product packaging or visit the official NITHO webBitte bewahren Sie Ihren Kaufbeleg für eventuelle Garantieansprüche auf.

For further assistance, you may contact NITHO customer service through their official channels.
