1. Einleitung
Vielen Dank für Ihren Einkauf.asing the CkeyiN MK707 4-in-1 Electric Milk Frother. This appliance is designed to create various milk foams and heat milk for your favorite beverages such as cappuccinos, lattes, and hot chocolates. Please read this manual carefully before use to ensure proper operation and maintenance.
2. Produktüberschreitungview
The CkeyiN MK707 features a powerful 500W motor and a 500ml capacity, offering four distinct functions for frothing and heating milk. Its design incorporates a non-stick interior for easy cleaning and an intelligent temperature control system.
Hauptmerkmale:
- 4-in-1-Funktionalität: Dense hot foam, airy hot foam, cold foam, and hot milk/chocolate milk.
- Hohe Leistung: 500W motor for quick frothing and heating.
- Große Kapazität: Up to 500ml for heating milk, suitable for multiple servings.
- Antihaft-Beschichtung: Stainless steel inner pot with non-stick coating for easy cleaning.
- Leiser Betrieb: Magnetic induction heating and frothing technology minimizes noise.
- Intelligente Temperaturregelung: Maintains optimal milk temperature (approx. 65±5℃ for hot milk).
Innere Struktur:
Image: Diagram of the CkeyiN Milk Frother's internal layers, including the anti-rust frosted outer layer, hard stainless steel layer, and nonstick coating layer.
Operational Highlights:
Image: The CkeyiN Milk Frother showcasing its key operational features: low noise (≤40db), fast frothing (90 seconds), intelligent temperature control, and anti-slip design.
3. Sicherheitshinweise
- Lesen Sie vor der Verwendung des Geräts alle Anweisungen.
- Do not immerse the main unit (housing) in water or other liquids. Only the inner pot is designed for contact with liquids.
- Stellen Sie sicher, dass das Netzkabel nicht beschädigt ist und von heißen Oberflächen ferngehalten wird.
- Do not operate the appliance if it has been damaged in any way. Contact customer service for assistance.
- Bewahren Sie das Gerät außerhalb der Reichweite von Kindern auf.
- Verwenden Sie das Gerät nur für den in dieser Bedienungsanleitung beschriebenen Zweck.
- Stellen Sie den Milchaufschäumer immer auf eine stabile, ebene und hitzebeständige Oberfläche.
- Ziehen Sie den Stecker aus der Steckdose, wenn Sie das Gerät nicht verwenden und bevor Sie es reinigen.
- Do not fill above the 'MAX' line to prevent overflow.
4. Einrichtung
Auspacken und Erstreinigung:
- Entfernen Sie sorgfältig sämtliches Verpackungsmaterial.
- Wash the inside of the frother jug and the whisk with warm, soapy water. Rinse thoroughly and dry.
- Wischen Sie die Außenseite des Milchaufschäumers mit einem Tuch ab.amp Tuch. Tauchen Sie das Hauptgerät nicht in Wasser.
Platzierung und Leistung:
- Place the frother on a dry, level, and stable surface.
- Stellen Sie sicher, dass das Netzkabel vollständig ausgezogen und an eine geerdete Steckdose angeschlossen ist.
Fill Level Guidelines:
Image: The interior of the CkeyiN Milk Frother showing the 'MIN' and 'MAX' fill lines. The maximum frothing capacity is 250ml (8.8oz), suitable for 3-5 people. The minimum frothing capacity is 100ml (3.4oz), suitable for 1-2 people.
- Observe the 'MIN' and 'MAX' markings inside the jug.
- For milk frothing, do not exceed the lower 'MAX' line (approx. 250ml / 8.8oz) to prevent overflow.
- For heating milk without frothing, you can fill up to the upper 'MAX' line (approx. 500ml).
- Always ensure the milk level is above the 'MIN' line.
5. Bedienungsanleitung
The CkeyiN MK707 offers four distinct modes for preparing your beverages. For best frothing results, it is recommended to use whole milk (fat content >3.0%).
Image: The CkeyiN Milk Frother illustrating its four functions: 1. Dense Hot Foam, 2. Airy Hot Foam, 3. Hot/Cold Foam, and 4. Heated Chocolate Milk.
Allgemeine Arbeitsschritte:
- Pour the desired amount of milk into the frother jug, ensuring it is between the 'MIN' and appropriate 'MAX' lines.
- Setzen Sie den Deckel fest auf den Krug.
- Press the corresponding function button on the frother's base to select your desired mode. The frother will start automatically.
- Once the process is complete, the frother will automatically shut off. Carefully remove the lid and pour the frothed or heated milk.
Detailed Mode Information:
Image: A table providing detailed parameters for different frothing and heating modes, including recommended capacity, frothing/heating time, and target temperature.
- 1. Dense Hot Foam: Ideal for cappuccinos. Capacity: 160ml. Frothing Time: Approx. 90 seconds. Temperature: 65±5℃ (149±41℉).
- 2. Airy Hot Foam: Suitable for lattes. Capacity: 160ml. Frothing Time: Approx. 90 seconds. Temperature: 65±5℃ (149±41℉).
- 3. Cold Foam: Perfect for iced coffees. Capacity: 160ml. Frothing Time: Approx. 90 seconds. Temperature: 25±5℃ (77±41℉).
- 4. Hot Milk / Hot Chocolate Milk: For warming milk or mixing with chocolate. Capacity: 160ml. Heating Time: 90-120 seconds. Temperature: 45-60-70-80℃ (113/140/158/176℉).
6. Reinigung und Wartung
Regular cleaning ensures optimal performance and extends the life of your milk frother.
Reinigungsschritte:
Image: Visual guide demonstrating the correct method for cleaning the CkeyiN Milk Frother's interior with a brush and water, and the incorrect method of washing the exterior directly under running water.
- Vor der Reinigung immer den Netzstecker des Milchaufschäumers ziehen.
- Lassen Sie den Milchaufschäumer nach Gebrauch vollständig abkühlen.
- Den Schneebesen aus dem Krug nehmen.
- Rinse the interior of the jug and the whisk with warm water immediately after use. The non-stick coating makes this easy. You may use a soft sponge or the provided cleaning brush with a small amount of mild dish soap.
- Wichtig: Do not wash the exterior of the frother directly with water. Wipe the exterior with a damp cloth only. The main unit cannot be immersed in water.
- Ensure no water overflows into the electrical components during cleaning.
- Dry all parts thoroughly before storing or next use.
7. Fehlerbehebung
If you encounter any issues with your CkeyiN Milk Frother, please refer to the following common problems and solutions:
| Problem | Mögliche Ursache | Lösung |
|---|---|---|
| Der Aufschäumer lässt sich nicht einschalten. | Keine Stromversorgung. | Prüfen Sie, ob das Netzkabel fest in einer funktionierenden Steckdose eingesteckt ist. |
| Die Milch schäumt nicht richtig auf. | Incorrect milk type or temperature. Too much/too little milk. | Use cold whole milk (fat content >3.0%). Ensure milk level is between MIN and frothing MAX line. |
| Während des Betriebs läuft Milch über. | Es wurde zu viel Milch hinzugefügt. | Do not exceed the 'MAX' line for frothing. Reduce milk quantity. |
| Ungewöhnliche Geräusche während des Betriebs. | Whisk not properly seated or foreign object. | Ensure the whisk is correctly placed at the bottom of the jug. Check for any obstructions. |
| Die Milch ist nicht heiß genug. | Incorrect mode selected or insufficient heating time. | Ensure the correct heating mode is selected. Allow the cycle to complete fully. |
8. Spezifikationen
- Marke: CkeyiN
- Modell: MK707
- Leistung: 500 W
- Kapazität: 500ml (max for heating), 250ml (max for frothing)
- Material: Stainless Steel (inner pot), PP (outer shell)
- Abmessungen: 8.31 x 7.76 x 7.09 Zoll
- Artikelgewicht: 2.49 Pfund
9. Garantie und Support
This product comes with a standard manufacturer's warranty. For detailed warranty information, technical support, or customer service inquiries, please refer to the contact information provided at the point of purchase or visit the official CkeyiN webBitte bewahren Sie Ihren Kaufbeleg für Garantieansprüche auf.
