BoxWave DirectSync Cable User Manual

1. Einleitung

The BoxWave DirectSync Cable is designed to provide reliable charging and high-speed data synchronization for your Yada RoadCam 1080p HD Dash Cam (BT58186-6/2). This manual outlines the features, setup, operation, maintenance, and specifications of your DirectSync Cable to ensure optimal performance.

Image 1.1: The BoxWave DirectSync Cable. This image displays the black USB-A to Micro-USB cable, coiled neatly.

2. Produktmerkmale

The DirectSync Cable offers several key features for efficient and durable use:

• Hi-Speed USB 2.0 Support: Facilitates data transfers at speeds up to 480Mbps.
• Dual-Functionality: Simultaneously charges your device and transfers data, enhancing convenience.
• Langlebige Konstruktion: Entwickelt für Langlebigkeit und gleichbleibende Leistung.
• Reinforced Strain Relief: Features strong rubberized grommet strain reliefs at connector points to prevent kinking and splitting, extending the cable's lifespan.
• Großzügige Länge: Bietet ample length for flexible placement and connection.

Image 2.1: The DirectSync Cable connected to a laptop and a smartphone, illustrating its charge and sync capabilities.

3. Einrichtungsanweisungen

Follow these steps to connect your DirectSync Cable:

1. Konnektoren identifizieren: The cable has a standard USB-A connector on one end and a Micro-USB connector on the other.
2. Anschluss an Strom/Computer: Insert the USB-A end of the cable into a compatible USB port on a power adapter, car charger, or computer.
3. Mit Gerät verbinden: Insert the Micro-USB end of the cable into the Micro-USB port on your Yada RoadCam 1080p HD Dash Cam.
4. Verbindung überprüfen: Ensure both ends are securely seated. Your device should indicate that it is charging or connected for data transfer.

4. Bedienungsanleitung

Using your DirectSync Cable for charging and data transfer:

4.1. Laden Sie Ihr Gerät auf

• Connect the cable as described in Section 3.
• When connected to a power source (e.g., wall adapter, car charger), your Yada RoadCam will begin charging.
• Monitor your device's screen for charging indicators.

4.2. Datenübermittlung

• Connect the USB-A end to a computer's USB port and the Micro-USB end to your Yada RoadCam.
• Your computer should recognize the connected device. You may need to select a 'data transfer' or 'mass storage' mode on your dash cam, if prompted.
• Greifen Sie auf die Einstellungen Ihres Geräts zu. files through your computer's file explorer to transfer videos, photos, or other data.

5. Wartung

Proper care will extend the life of your DirectSync Cable:

• Lagerung: Store the cable in a cool, dry place away from direct sunlight and extreme temperatures. Avoid tightly coiling or bending the cable at sharp angles.
• Reinigung: Gently wipe the cable and connectors with a dry, soft cloth to remove dust or debris. Do not use liquid cleaners or abrasive materials.
• Handhabung: Always grasp the connector head when plugging or unplugging the cable. Avoid pulling directly on the cable itself, as this can damage the internal wires or strain relief.

Bild 5.1: Eine Nahaufnahme view of the reinforced strain relief on the DirectSync Cable, designed to prevent damage from bending.

6. Fehlerbehebung

If you encounter issues with your DirectSync Cable, consider the following:

• Cable Not Charging:
  • Stellen Sie sicher, dass beide Enden des Kabels fest angeschlossen sind.
  • Versuchen Sie es mit einer anderen Stromquelle oder einem anderen USB-Anschluss.
  • Test the cable with another compatible device, if available, to determine if the issue is with the cable or the device/power source.
• Cable Not Syncing Data:
  • Verify the cable is firmly connected to both your device and computer.
  • Ensure your computer's operating system and device drivers are up to date.
  • Check your Yada RoadCam settings to ensure it is set to 'data transfer' or 'mass storage' mode when connected to a computer.
  • Probieren Sie einen anderen USB-Anschluss an Ihrem Computer aus.
• Physischer Schaden: Inspect the cable for any visible signs of damage, such as cuts, fraying, or bent connectors. A damaged cable should be replaced.

7. Spezifikationen

Image 7.1: A measuring tape indicating the cable's approximate length of 3 feet.

Image 7.2: The Hi-Speed USB 2.0 logo, indicating the cable's data transfer standard.

8. Garantie und Support

For information regarding the warranty of your BoxWave DirectSync Cable, please refer to the official BoxWave website or contact BoxWave customer support directly. Any specific technical support for the Yada RoadCam 1080p HD Dash Cam (BT58186-6/2) should be directed to Yada's official support channels.
